| Primary nominal RMS current (A) | 50 |
|---|---|
| Measuring range (A) | ±150 |
| Supply voltage (V) | ±12...15 |
| Secondary output | ±4V |
| Accuracy (%) | ±1.0 |
| Output bandwidth | 50 |
| Operating temperature (°C) | -40~105 |
| Copper busbar (mm) | 10 x 12mm（Three holes） |
| PCB | |
| Others | HX PZ2.54-1X6P WZ |
